Description
12 Watt - LED Direct Wire Downlight - Edge-lit - 6 inch - CCT Selectable - 120 volt - Dimmable - Square - Remote Driver - Black Finish
Product Specification
Air Tight
Yes
Avg Rated Hours
50000.0
Base
Integrated
Battery Back-up
No
Beam Spread
108
Brightness (Lumens)
750L
Bulb Included
Integrated
Bulbs
1.0
CA Prop 65
Lead
CA Web Text
California T24 Listed
CCT Selectable
Yes
Case Cubic Ft.
1.1822
Case Height In.
8.11
Case Length In.
18.07
Case Quantity
12
Case UPC
10045900000000.0
Case Weight Lb.
16.53
Case Width In.
13.94
Ceiling Aperture
6.188 in. Cutout
Color Rendering Index (CRI)
90+
Color of Light
Warm to Cool White
Connection
Direct Wired
Country of Origin
Vietnam
DLC Approved
No
Dimension String
L:6.69" W:6.69" H:0.90"
Dimmable
Yes-Dimmable
Dimmable Function
120V only
Each Cubic Ft.
0.0768
Each Quantity
1.0
Finish Family
Black
Fixture Type
Remote Driver LED Downlight
Fixture/Body Finish
Black
Height In.
0.9
IC Rated
Yes
IOT Enabled
No
IP Rating
IP20
Indoor / Outdoor
Indoor;Outdoor
Kelvin Temperature
2700K/3000K/3500K/4000K/5000K
Lamp Base
Integrated
Lamp Shape
Integrated LED
Lens Finish
Frost
Lens Material
Poly methyl methacrylate (PMMA)
Location Rating
Wet
Material
Aluminum
Mounting Procedure
Recessed Direct Wire
Operating Frequency
60Hz
Operating Temp
-20C (-4F) to +45C (+113F)
Pack Type
Box
Power Factor
>0.9
Replaceable Light Source
No
RoHS Compliant
Yes
SDS class
LED_Lamp
Safety Listing
cETLus - Listed
Shape
Square
Status
Active
Style
Utility
Surge Protection
Built-in surge protection - 1.5KV
THD
<20%
Tariff Code
9405.11.8010
Technology
LED
Trim Color
Black
Type
Fixtures
UNSPSC
39111515
Voltage
120V
Voltage Text
AC Only
Warranty
5 Year Limited - Fixtures
Wattage Selectable
No
Weight Lb.
1.16
Width In.
6.69
Warranty Information
Standard Manufacturer's Limited Warranty
