Description
| Manufacturer Documents: » Download the Satco 62-1724 Spec Sheet (PDF) | Installation Instructions (PDF) | Dimensional Drawing (PDF) |
The Satco Nuvo 62-1724 is a Blink Pro, finished in White. It has an integrated LED light source: 13W, 1200-1300 lumens, 2700K/3000K/3500K/4000K/5000K (selectable), 90+ CRI. It measures length 9.00", width 9.00", height 0.67" and is rated for wet locations. It runs on 120V, is dimmable (Reverse Phase; 120V only) and is cETLus listed. A good fit for bedrooms, hallways, closets and kitchens.
Key Features
- Integrated LED featuring 13 watts, CCT Selectable from warm to natural light, 90 CRI
- Fixture is dimmable, selectable from 1200 to 1300 lumens, with a beam spread of 100
- 9 inch Length x 9 inch Width x 0.67 inch Height
- White Finish with Acrylic Panel
- Ideal for corridors, closets, kitchens, bathrooms, bedrooms, including outdoors as they are wet location rated with closed ceiling applications
- Rated for 50,000 hours
- Visit Satco.com for optional accessories: 9 inch square extension collar; White - 25-1724, Black - 25-1725, Bronze - 25-1726
- Easy installation with included instructions
Specifications at a Glance
| General | |
|---|---|
| Brand | Satco Nuvo |
| Part Number | 62-1724 |
| UPC | 045923625756 |
| Product Type | Flush Mount |
| Style | Utility |
| Finish | White |
| Material | Die-Cast Aluminum |
| Light Source & Electrical | |
| Bulb Included | Integrated |
| Wattage | 13W |
| Lumens | 1200L-1300L |
| Color Temperature | 2700K/3000K/3500K/4000K/5000K |
| CRI | 90+ |
| Voltage | 120V |
| Dimmable | Yes-Dimmable |
| Dimming | Reverse Phase, 120V only |
| Beam Spread | 100 |
| Rated Life (hours) | 50000 |
| Dimensions & Mounting | |
| Dimensions | L:9.00" W:9.00" H:0.67" |
| Height (in) | 0.67 |
| Width (in) | 9 |
| Mounting | Ceiling |
| Sloped Ceiling Compatible | Yes |
| Fixture Weight (lb) | 1.46 |
| Ratings & Compliance | |
| Indoor / Outdoor | Indoor |
| Location Rating | Wet |
| Safety Listing | cETLus - Listed |
| California | California T24 Listed |
| Warranty | 5-Years |
| Country of Origin | Thailand |
| Packaging | |
| Sold | Each (box) |
| Case Quantity | 12 |
| Shipping Weight (lb) | 1.65 |
| Replaces | S21517, S29340, S29343, S29363, S9340, S9343, S9363 |
Warranty Information
Standard Manufacturer's Limited Warranty
