Description
| Manufacturer Documents: » Download the Satco 62-1774 Spec Sheet (PDF) | Installation Instructions (PDF) | Dimensional Drawing (PDF) |
The Satco Nuvo 62-1774 is a Blink Pro Plus, finished in White. It has an integrated LED light source: 47W, 3600-4050 lumens, 2700K/3000K/3500K/4000K/5000K (selectable), 90+ CRI. It measures length 23.70", width 23.70", height 1.06" and is rated for damp locations. It runs on 120V/277V, is dimmable (Forward Phase or Reverse Phase; 120V only) and is cETLus listed. A good fit for bedrooms, hallways, closets and kitchens.
Key Features
- Integrated LED featuring 47 watts, CCT Selectable from warm to natural light, 90 CRI
- Fixture is dimmable, selectable from 3600 to 4050 lumens
- Dimensions: 23.70 in L x 23.70 in W x 1.06 in H
- White Finish with Acrylic Panel
- Ideal for utility, basements, kitchens, garages, bathrooms, bedrooms, hallways
- Rated for 50,000 hours
- Easy installation with included instructions
- Visit Satco.com for our entire line of BLINK products
Specifications at a Glance
| General | |
|---|---|
| Brand | Satco Nuvo |
| Part Number | 62-1774 |
| UPC | 045923613036 |
| Product Type | Surface Mount |
| Style | Contemporary |
| Finish | White |
| Material | Die-Cast Aluminum |
| Light Source & Electrical | |
| Bulb Included | Integrated |
| Wattage | 47W |
| Lumens | 3600L-4050L |
| Color Temperature | 2700K/3000K/3500K/4000K/5000K |
| CRI | 90+ |
| Voltage | 120V/277V |
| Dimmable | Yes-Dimmable |
| Dimming | Forward Phase or Reverse Phase, 120V only |
| Beam Spread | 110 |
| Rated Life (hours) | 50000 |
| Dimensions & Mounting | |
| Dimensions | L:23.70" W:23.70" H:1.06" |
| Height (in) | 1.06 |
| Width (in) | 23.7 |
| Mounting | Ceiling |
| Fixture Weight (lb) | 8.65 |
| Ratings & Compliance | |
| Indoor / Outdoor | Indoor |
| Location Rating | Damp |
| Safety Listing | cETLus - Listed |
| California | California T24 Listed |
| Warranty | 5-Years |
| Country of Origin | Thailand |
| Packaging | |
| Sold | Each (box) |
| Case Quantity | 3 |
| Shipping Weight (lb) | 11.12 |
| Replaces | 62-1053, 62-1153, 62-1253 |
Warranty Information
Standard Manufacturer's Limited Warranty
