Description
| Manufacturer Documents: » Download the Satco 63-402 Spec Sheet (PDF) | Installation Instructions (PDF) |
The Satco Nuvo 63-402 is a 4 Watt 10-Inch LED Under Cabinet, finished in White. It has an integrated LED light source: 4W, 250 lumens, 3000K/4000K/5000K (selectable), 90+ CRI. It measures length 10.00", width 0.70", height 0.78", depth 0.78" and is rated for damp locations. It runs on 120V, is dimmable (Forward Phase) and is cETLus listed.
Key Features
- 3-CCT Selectable
- 90 CRI High Quality Light
- 4W, 10 Inch, White Finish
- Low Profile Design
- On Board IC Driver - No External Driver Required
- Damp Location Rated
- 50,000 Hour Functional Life
Specifications at a Glance
| General | |
|---|---|
| Brand | Satco Nuvo |
| Part Number | 63-402 |
| UPC | 045923630378 |
| Product Type | Under Cabinet |
| Style | Contemporary |
| Finish | White |
| Material | Polycarbonate (PC) |
| Light Source & Electrical | |
| Bulb Included | Integrated |
| Wattage | 4W |
| Lumens | 250L |
| Color Temperature | 3000K/4000K/5000K |
| CRI | 90+ |
| Voltage | 120V |
| Dimmable | Yes-Dimmable |
| Dimming | Forward Phase |
| Beam Spread | 110 |
| Rated Life (hours) | 50000 |
| Dimensions & Mounting | |
| Dimensions | L:10.00" W:0.70" H:0.78" D:0.78" |
| Height (in) | 0.78 |
| Width (in) | 0.7 |
| Mounting | Under Cabinet Clip |
| Fixture Weight (lb) | 0.13 |
| Ratings & Compliance | |
| Indoor / Outdoor | Indoor |
| Location Rating | Damp |
| Safety Listing | cETLus - Listed |
| California | Lawful for sale |
| Warranty | 5-Years |
| Country of Origin | Thailand |
| Packaging | |
| Sold | Each (box) |
| Case Quantity | 48 |
| Shipping Weight (lb) | 0.22 |
