Description
| Manufacturer Documents: » Download the Satco 86-216 Spec Sheet (PDF) | Installation Instructions (PDF) | Dimensional Drawing (PDF) |
The Satco Nuvo 86-216 is a Temporary work Light, finished in Frost. It has an integrated LED light source: 10W/12W/24W, 750/950/1800 lumens, 3000K, 90+ CRI. It measures length 5.91", width 4.59" and is rated for wet locations. It runs on 12V-34V, is dimmable (Step Dimming; Only dimmable through wattage selection switch on lamp. NOT dimmable with wall dimmers or any other dimming controls.) and is cETLus listed. A good fit for parking lots, building exteriors, yards and job sites.
Key Features
- CEC: Lawful for sale in California
- Dimmable: Yes - Dimmable
- Indoor use
- For use with remote drivers
- Operating Temperature: -20C (-4F) to a maximum of 45C (113F)
Specifications at a Glance
| General | |
|---|---|
| Brand | Satco Nuvo |
| Part Number | 86-216 |
| UPC | 045923862168 |
| Product Type | Work Light |
| Style | Utility |
| Finish | Frost |
| Material | Plastic |
| Light Source & Electrical | |
| Bulb Included | Integrated |
| Wattage | 10W/12W/24W |
| Lumens | 750L/950L/1800L |
| Color Temperature | 3000K |
| CRI | 90+ |
| Voltage | 12V-34V |
| Dimmable | Yes-Dimmable |
| Dimming | Step Dimming, Only dimmable through wattage selection switch on lamp. NOT dimmable with wall dimmers or any other dimming controls. |
| Beam Spread | 280 |
| Rated Life (hours) | 25000 |
| Dimensions & Mounting | |
| Dimensions | L:5.91" W:4.59" |
| Width (in) | 4.59 |
| Mounting | Plug in and Hook |
| Includes | Driver not included |
| Fixture Weight (lb) | 0.4 |
| Ratings & Compliance | |
| Indoor / Outdoor | Indoor |
| Location Rating | Wet |
| Safety Listing | cETLus - Listed |
| California | Lawful for sale |
| Warranty | 5-Years |
| Country of Origin | China |
| Packaging | |
| Sold | Each (box) |
| Case Quantity | 24 |
| Shipping Weight (lb) | 0.51 |
Warranty Information
Standard Manufacturer's Limited Warranty
