Description
| Manufacturer Documents: » Download the Satco 65-758 Spec Sheet (PDF) | Installation Instructions (PDF) | Dimensional Drawing (PDF) |
The Satco Nuvo 65-758 is a CCT and Wattage Adjustable LED Wall Pack, finished in Bronze. It has an integrated LED light source: 80W/100W/120W, 11360-17400 lumens, 3000K/4000K/5000K (selectable), 80+ CRI. It measures width 14.36", height 9.35", extension 7.39" and is rated for wet locations. It runs on 120V-347V, is dimmable (0-10V Dimming) and is cULus certified. A good fit for building perimeters, parking areas, loading docks and walkways.
Key Features
- Wattage Selectable 80W/100W/120W
- CCT Selectable 3000K/4000K/5000K
- Integrated by-passable photocell
- 4KV Surge Protection
- 50,000 Hours
- DLC Premium
Specifications at a Glance
| General | |
|---|---|
| Brand | Satco Nuvo |
| Part Number | 65-758 |
| UPC | 045923670787 |
| Product Type | Wall Pack |
| Style | Traditional |
| Finish | Bronze |
| Material | Die-Cast Aluminum |
| Light Source & Electrical | |
| Bulb Included | Integrated |
| Wattage | 80W/100W/120W |
| Lumens | 11360L-17400L |
| Color Temperature | 3000K/4000K/5000K |
| CRI | 80+ |
| Voltage | 120V-347V |
| Dimmable | Yes-Dimmable |
| Dimming | 0-10V Dimming |
| Beam Spread | 110 |
| Rated Life (hours) | 50000 |
| Dimensions & Mounting | |
| Dimensions | W:14.36" H:9.35" E:7.39" |
| Height (in) | 9.35 |
| Width (in) | 14.36 |
| Extends (in) | 7.39 |
| Mounting | Wall |
| Fixture Weight (lb) | 9.5 |
| Ratings & Compliance | |
| Indoor / Outdoor | Indoor, Outdoor |
| Location Rating | Wet |
| IP Rating | IP65 |
| Safety Listing | cULus - Certified |
| DLC | Premium |
| California | Lawful for sale |
| Warranty | 5-Years |
| Country of Origin | Vietnam |
| Packaging | |
| Sold | Each (box) |
| Case Quantity | 1 |
| Shipping Weight (lb) | 10.14 |
Warranty Information
Standard Manufacturer's Limited Warranty
